SCHNEIDER 140CPU65160 中央處理器
1.產 品 資 料 介 紹：
中文資料：
SCHNEIDER 140CPU65160中央處理器是施耐德昆騰系列的一款產品，它在工業自動化和控制系統中扮演著關鍵角色，負責執行用戶編寫的控制邏輯、監視過程和處理輸入輸出信號。
在功能方面，該中央處理器模塊具有強大的處理能力，可以處理大規模的控制任務。它支持多種通信接口，如以太網、串行通信等，以與其他PLC模塊、外部設備和上層監控系統進行通信。此外，它提供用于存儲用戶編寫的控制程序的內存空間，包括RAM（隨機存取存儲器）和閃存，并集成了實時時鐘以支持時間戳和時間相關的控制功能。
在結構和特點上，140CPU65160具有1個循環/周期性主任務，1個周期性快速任務，128個I/O中斷任務和32個定時器中斷任務，以及4項輔助任務。這種結構使得處理器能夠高效地處理各種任務，并快速響應各種事件。同時，該處理器還具有本地信令功能，包括用于以太網連接的綠色LED燈和用于指示以太網沖突的紅色紅燈，方便用戶進行故障排查。
此外，該處理器在I/O能力上表現出色，擁有2/3/4/6/10/16插槽，本地I/O 2機架（1主+1擴展），遠程I/O（RIO）31個具有2個機架的遠程站（1主+1擴展），以及分布式I/O（DIO）擁有63個單機架分布站的3個網絡。這些特性使得它能夠連接和管理大量的輸入輸出設備，滿足復雜控制系統的需求。
在電氣連接方面，該處理器配備了豐富的接口，包括1個USB端口、2個分布式as接口和4個遠程接口、6個本地以太網TCP/IP、6個本地Modbus Plus、6個本地Profibus DP和1個Modbus RS232/485。此外，它還包括一個用于連接Modbus Plus網絡的母連接器SUB-D 9、一個用于連接以太網網絡的RJ45連接器和一個專門設計用于連接Modbus總線的RJ45連接器。
英文資料：
SCHNEIDER 140CPU65160 central processor is a product of the Schneider Kunteng series, which plays a crucial role in industrial automation and control systems, responsible for executing user written control logic, monitoring processes, and processing input and output signals.
In terms of functionality, the central processing unit module has powerful processing capabilities and can handle large-scale control tasks. It supports multiple communication interfaces, such as Ethernet, serial communication, etc., to communicate with other PLC modules, external devices, and upper level monitoring systems. In addition, it provides memory space for storing user written control programs, including RAM (Random Access Memory) and flash memory, and integrates real-time clocks to support timestamp and time related control functions.
In terms of structure and characteristics, 140CPU65160 has 1 cyclic/periodic main task, 1 periodic fast task, 128 I/O interrupt tasks and 32 timer interrupt tasks, as well as 4 auxiliary tasks. This structure enables the processor to efficiently process various tasks and respond quickly to various events. At the same time, the processor also has local signaling functions, including green LED lights for Ethernet connections and red lights for indicating Ethernet conflicts, making it convenient for users to troubleshoot.
In addition, the processor performs excellently in I/O capabilities, with 2/3/4/6/10/16 slots, 2 local I/O racks (1 main+1 expansion), 31 remote I/O (RIO) stations with 2 racks (1 main+1 expansion), and 3 networks with 63 single rack distribution stations for distributed I/O (DIO). These features enable it to connect and manage a large number of input and output devices, meeting the needs of complex control systems.
In terms of electrical connections, the processor is equipped with a variety of interfaces, including 1 USB port, 2 distributed AS interfaces, and 4 remote interfaces, 6 local Ethernet TCP/IP, 6 local Modbus Plus, 6 local Profibus DP, and 1 Modbus RS232/485. In addition, it also includes a female connector SUB-D 9 for connecting Modbus Plus networks, an RJ45 connector for connecting Ethernet networks, and an RJ45 connector specifically designed for connecting Modbus buses.
2.產 品 展 示
