NI PXI-4461 186900T-11L聲音與振動模塊
1.產 品 資 料 介 紹：
中文資料：
NI PXI-4461是國家儀器公司（National Instruments, NI）生產的一款聲音與振動模塊，設計用于高精度的聲音和振動信號測量與分析。以下是關于NI PXI-4461聲音與振動模塊的基本信息和特點：
基本信息
- 制造商: National Instruments (NI)
- 型號: PXI-4461
- 產品代碼: 186900T-11L
主要特點
多通道測量:
- 雙通道輸入: 提供兩個24位模擬輸入通道，用于高精度聲音和振動信號的采集。
- 雙通道輸出: 提供兩個24位模擬輸出通道，用于信號生成和控制。
高精度和高動態范圍:
- 24位分辨率: 確保采集的聲音和振動信號具有高精度和低噪聲。
- 高動態范圍: 高達110 dB的動態范圍，適用于寬幅度范圍內的信號測量。
高采樣率:
- 采樣率: 高達204.8 kS/s的采樣率，能夠精確捕捉快速變化的聲音和振動信號。
信號分析和生成:
- 信號生成: 內置信號生成功能，支持多種波形輸出（如正弦波、方波、三角波等），用于系統測試和校準。
- 頻譜分析: 支持實時頻譜分析，便于對聲音和振動信號進行頻域分析。
軟件支持:
- LabVIEW: 兼容NI LabVIEW軟件，提供強大的數據采集、信號處理和分析功能。
- Sound and Vibration Toolkit: 支持NI的聲音與振動工具包，簡化復雜的聲音與振動測量和分析任務。
應用領域:
- 聲音測試: 適用于麥克風測試、聲學測量、噪聲分析等應用。
- 振動分析: 用于機械振動監測、結構健康監測、振動分析等領域。
- 傳感器校準: 用于加速度計和其他傳感器的校準和性能測試。
設計和安裝:
- PXI平臺: 設計為PXI模塊，易于與其他PXI模塊集成，構建多功能測試和測量系統。
- 模塊化設計: 緊湊的模塊化設計，便于安裝、配置和維護。
堅固耐用:
- 工業級設計: 具備良好的抗干擾能力和穩定性，適用于苛刻的工業環境。
總結
NI PXI-4461聲音與振動模塊是一款高性能的測量設備，專為精確的聲音和振動信號測量和分析而設計。通過其高精度、多通道、高動態范圍和高采樣率，能夠滿足各種復雜的聲音與振動測量需求。其與NI LabVIEW和聲音與振動工具包的無縫集成，使其成為聲學測量、振動分析和傳感器校準等領域中的理想選擇。
英文資料
NI PXI-4461 is a sound and vibration module produced by National Instruments (NI), designed for high-precision measurement and analysis of sound and vibration signals. The following is the basic information and characteristics about the NI PXI-4461 Sound and Vibration Module:
Basic information
Manufacturer: National Instruments (NI)
Model: PXI-4461
Product code: 186900T-11L
main features
Multi channel measurement:
Dual channel input: Provides two 24 bit analog input channels for high-precision acquisition of sound and vibration signals.
Dual channel output: Provides two 24 bit analog output channels for signal generation and control.
High precision and high dynamic range:
24 bit resolution: Ensure that the collected sound and vibration signals have high accuracy and low noise.
High dynamic range: up to 110 dB dynamic range, suitable for signal measurement over a wide range.
High sampling rate:
Sampling rate: Up to 204.8 kS/s, capable of accurately capturing rapidly changing sound and vibration signals.
Signal analysis and generation:
Signal generation: Built in signal generation function, supporting multiple waveform outputs (such as sine wave, square wave, triangular wave, etc.), for system testing and calibration.
Spectrum analysis: Supports real-time spectrum analysis, making it easy to perform frequency domain analysis on sound and vibration signals.
Software support:
LabVIEW: Compatible with NI LabVIEW software, providing powerful data acquisition, signal processing, and analysis functions.
Sound and Vibration Toolkit: Supports NI's sound and vibration toolkit, simplifying complex sound and vibration measurement and analysis tasks.
Application field:
Sound testing: suitable for microphone testing, acoustic measurement, noise analysis and other applications.
Vibration analysis: used in fields such as mechanical vibration monitoring, structural health monitoring, and vibration analysis.
Sensor calibration: used for calibration and performance testing of accelerometers and other sensors.
Design and installation:
PXI platform: designed as a PXI module, easy to integrate with other PXI modules, and build a multifunctional testing and measurement system.
Modular design: Compact modular design, easy to install, configure, and maintain.
Durable and sturdy:
Industrial grade design: With good anti-interference ability and stability, suitable for harsh industrial environments.
summary
The NI PXI-4461 Sound and Vibration Module is a high-performance measurement device designed for precise measurement and analysis of sound and vibration signals. Through its high precision, multi-channel, high dynamic range, and high sampling rate, it can meet various complex sound and vibration measurement needs. Its seamless integration with NI LabVIEW and sound and vibration toolkits makes it an ideal choice in fields such as acoustic measurement, vibration analysis, and sensor calibration.
2.產 品 展 示
