Bently 3500/15E 164949-01電源模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Bently 3500/15E 164949-01 電源模塊 是 Bently Nevada 3500 系列監控系統中的一部分，主要用于為系統提供可靠的電源支持。Bently Nevada 是一款廣泛應用于振動監測和設備狀態監測的技術品牌，3500 系列監控系統尤其在工業環境中用于機器健康監測與保護。下面是關于 3500/15E 電源模塊的一些關鍵特點與應用信息：
主要特點：
電源管理功能：
- 3500/15E 電源模塊提供穩壓電源，以確保系統中其他模塊的穩定運行。它主要用于為 Bently Nevada 3500 系列的其他模塊（如傳感器信號處理模塊、報警模塊、顯示模塊等）提供穩定的直流電源。
- 該模塊支持寬范圍的輸入電壓，可以適應不同的電力環境，確保設備在不同電力條件下的穩定運行。
高可靠性：
- 作為一款關鍵的電源模塊，3500/15E 164949-01 電源模塊具有高可靠性，通常用于需要持續、不間斷電力供應的工業應用中。這使得它非常適合在動力設備監控和保護系統中使用，尤其是在發電廠、石油天然氣、化工廠等對設備穩定性要求極高的環境。
冗余設計：
- 為了提高系統的容錯能力，3500 系列監控系統通?？梢灾С蛛娫茨K的冗余配置。這意味著如果一個電源模塊出現故障，備用模塊可以接管供電，確保系統的持續運行和數據不丟失。
系統兼容性：
- Bently 3500/15E 電源模塊與 Bently Nevada 3500 系列中的其他監控模塊兼容，包括 3500/32 振動監測模塊、3500/42 溫度監測模塊、3500/22 流量監測模塊等。它是這些模塊的核心組件之一，提供穩定電源以保證系統的高效運行。
安裝與維護：
- 電源模塊通常安裝在一個機架式系統中。其設計易于集成和維護，能夠快速更換或升級。其模塊化設計使得整個監控系統的維護變得更加簡便。
- 定期檢查和測試電源模塊的運行狀況是確保系統正常工作的一項重要任務。
保護與故障報警：
- 該電源模塊具有過載保護、短路保護、過溫保護等多種安全特性，可以防止因電氣問題引起的系統故障。
- 如果電源模塊發生故障，它通常會通過系統報警通知用戶或操作員進行干預。
技術規格：
- 輸入電壓范圍：通常為 85-264 VAC 或 100-240 VDC（具體取決于配置）。
- 輸出電壓：通常為 24 VDC，用于為 3500 系列模塊提供所需電力。
- 輸出功率：足夠為多個模塊提供穩定的電力支持。
- 冗余配置：支持冗余電源配置，確保高可用性。
- 溫度范圍：支持在工業環境下的較寬工作溫度范圍，通常為 -40°C 到 +70°C。
英文資料：
The Bently 3500/15E 164949-01 power module is part of the Bently Nevada 3500 series monitoring system and is primarily used to provide reliable power support for the system. Bently Nevada is a technology brand widely used for vibration monitoring and equipment condition monitoring. The 3500 series monitoring system is particularly used for machine health monitoring and protection in industrial environments. Here are some key features and application information about the 3500/15E power module:
Main features:
Power management function:
The 3500/15E power module provides a regulated power supply to ensure the stable operation of other modules in the system. It is mainly used to provide stable DC power for other modules in the Bently Nevada 3500 series, such as sensor signal processing modules, alarm modules, display modules, etc.
This module supports a wide range of input voltages and can adapt to different power environments, ensuring stable operation of equipment under different power conditions.
High reliability:
As a critical power module, the 3500/15E 164949-01 power module has high reliability and is typically used in industrial applications that require continuous, uninterrupted power supply. This makes it very suitable for use in power equipment monitoring and protection systems, especially in environments such as power plants, oil and gas, chemical plants, etc. that require extremely high equipment stability.
Redundant design:
In order to improve the fault tolerance of the system, the 3500 series monitoring system usually supports redundant configuration of power modules. This means that if a power module fails, the backup module can take over the power supply, ensuring the continuous operation of the system and preventing data loss.
System compatibility:
The Bently 3500/15E power module is compatible with other monitoring modules in the Bently Nevada 3500 series, including the 3500/32 vibration monitoring module, 3500/42 temperature monitoring module, 3500/22 flow monitoring module, etc. It is one of the core components of these modules, providing stable power to ensure efficient operation of the system.
Installation and maintenance:
Power modules are typically installed in a rack mounted system. Its design is easy to integrate and maintain, and can be quickly replaced or upgraded. Its modular design makes the maintenance of the entire monitoring system easier.
Regular inspection and testing of the operation status of the power module is an important task to ensure the normal operation of the system.
Protection and fault alarm:
This power module has various safety features such as overload protection, short circuit protection, and over temperature protection, which can prevent system failures caused by electrical problems.
If the power module malfunctions, it usually notifies the user or operator to intervene through a system alarm.
Technical specifications:
Input voltage range: typically 85-264 VAC or 100-240 VDC (depending on configuration).
Output voltage: typically 24 VDC, used to provide the required power for 3500 series modules.
Output power: sufficient to provide stable power support for multiple modules.
Redundant configuration: Supports redundant power configuration to ensure high availability.
Temperature range: Supports a wide operating temperature range in industrial environments, typically from -40 ° C to+70 ° C.
2.產 品 展 示
