Motorola MVME2400-0361 單板計算機 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Motorola MVME2400-0361 單板計算機 是 Motorola（現為 NXP Semiconductors）生產的一款高性能 VME（Versa Modular Europe）總線 兼容的單板計算機。它通常應用于工業自動化、嵌入式計算、軍事和航天等領域，提供可靠的計算和控制能力，適用于需要高性能和長期穩定性的環境。
主要特點：
高性能處理器：
- MVME2400-0361 配備了一款 PowerPC 603e 處理器，主頻高達 180 MHz。
- PowerPC 架構廣泛應用于嵌入式系統，具有出色的計算能力和高效能。
VME 總線兼容：
- 支持 VME 64 總線（版本 3.x），提供 高帶寬 和 高速數據傳輸，適合需要大數據量處理的系統。
- 可作為 主控制單元 或 從設備 使用，支持多個并行工作模塊。
內存與擴展性：
- 提供高達 128 MB 的 SDRAM（可以根據具體配置有所不同），滿足大多數嵌入式計算需求。
- 具有 2 MB 的 Flash 存儲，可用于存儲系統固件和應用程序。
- 支持?jǐn)U展內存，并通過 PCMCIA 插槽 支持其他存儲設備（如 CF 卡等）。
多種 I/O 接口：
- 配備 串口、并口、網絡接口（如 10/100 Ethernet），支持 USB 接口等，能夠與各種外部設備和控制系統連接。
- 提供 數字 I/O 和 模擬 I/O 接口，可以用于傳感器采集、執行器控制等任務。
操作系統支持：
- 支持多種操作系統，包括 VxWorks、Linux 和 RTOS（實時操作系統），使得它能夠適應各種實時性和穩定性要求的應用。
冗余和可靠性：
- 該單板計算機設計具有 高可靠性，可以長期穩定運行，適應 惡劣環境（如高溫、低溫和振動等）下的應用。
- 配備了 看門狗定時器、硬件故障檢測等功能，確保系統在出現故障時能及時恢復或報警。
圖形與顯示功能：
- 提供 圖形加速器，適用于需要圖形用戶界面的應用（如 HMI 監控、工業控制顯示等）。
應用領域：
工業自動化：
- 用于控制系統、數據采集、監測和分析等工業應用。MVME2400 常見于 PLC 控制系統、機器人控制等場合。
嵌入式系統：
- 在 醫療設備、通信設備、航天系統等嵌入式系統中得到廣泛應用，支持實時數據處理和控制。
軍事和航天：
- 因其高可靠性和穩定性，MVME2400 系列廣泛用于 軍事 和 航天 應用，尤其是在需要高耐久性的控制系統中。
交通與物流：
- 用于 智能交通系統、運輸監控系統，以及 高速鐵路、航空航天等系統中，進行實時數據處理和監控。
技術規格：
| 參數 | 說明 |
|---|---|
| 處理器 | PowerPC 603e, 180 MHz |
| 內存 | 128 MB SDRAM |
| 存儲 | 2 MB Flash |
| VME 總線 | VME 64（版本 3.x） |
| 網絡接口 | 10/100 Ethernet (可選高速以太網接口) |
| 串行端口 | 4 x RS-232 或 2 x RS-232 和 1 x RS-422/485 |
| I/O 接口 | 數字 I/O, 模擬 I/O, 串口, USB, 并口等 |
| 擴展槽 | 1 x PMC 插槽, 1 x PCMCIA 插槽 |
| 電源要求 | +5V DC (標準電源輸入) |
| 尺寸 | 6U (233 x 160 x 40 mm) |
| 操作系統支持 | VxWorks, Linux, RTOS (實時操作系統) |
| 防護等級 | 適應工業環境要求，防震動、防塵、防水 |
英文資料：
The Motorola MVME2400-0361 single board computer is a high-performance VME (Versa Modular Europe) bus compatible single board computer produced by Motorola (now NXP Semiconductors). It is commonly used in fields such as industrial automation, embedded computing, military, and aerospace, providing reliable computing and control capabilities, suitable for environments that require high performance and long-term stability.
Main features:
High performance processor:
MVME2400-0361 is equipped with a PowerPC 603e processor with a clock speed of up to 180 MHz.
The PowerPC architecture is widely used in embedded systems and has excellent computing power and high efficiency.
VME bus compatibility:
Supports VME 64 bus (version 3. x), providing high bandwidth and high-speed data transmission, suitable for systems that require large amounts of data processing.
Can be used as a master control unit or slave device, supporting multiple parallel working modules.
Memory and Scalability:
Provide up to 128 MB of SDRAM (which may vary depending on specific configurations) to meet most embedded computing needs.
Featuring 2 MB of Flash storage, it can be used to store system firmware and applications.
Support for expanding memory and supporting other storage devices (such as CF cards) through PCMCIA slots.
Multiple I/O interfaces:
Equipped with serial port, parallel port, network interface (such as 10/100 Ethernet), supporting USB interface, etc., it can connect with various external devices and control systems.
Provide digital I/O and analog I/O interfaces, which can be used for tasks such as sensor acquisition and actuator control.
Operating system support:
Supports multiple operating systems, including VxWorks, Linux, and RTOS (real-time operating system), enabling it to adapt to applications with various real-time and stability requirements.
Redundancy and reliability:
This single board computer design has high reliability, can operate stably for a long time, and is suitable for applications in harsh environments such as high temperature, low temperature, and vibration.
Equipped with watchdog timer, hardware fault detection and other functions to ensure timely recovery or alarm in case of system failure.
Graphics and display functions:
Provide a graphics accelerator suitable for applications that require a graphical user interface, such as HMI monitoring, industrial control displays, etc.
Application areas:
Industrial automation:
Used for industrial applications such as control systems, data acquisition, monitoring, and analysis. MVME2400 is commonly used in PLC control systems, robot control, and other applications.
Embedded system:
Widely used in embedded systems such as medical equipment, communication equipment, and aerospace systems, it supports real-time data processing and control.
Military and Aerospace:
Due to its high reliability and stability, the MVME2400 series is widely used in military and aerospace applications, especially in control systems that require high durability.
Transportation and Logistics:
Used for real-time data processing and monitoring in intelligent transportation systems, transportation monitoring systems, as well as high-speed railway, aerospace and other systems.
Technical specifications:
Parameter Description
Processor PowerPC 603e, 180 MHz
Memory 128 MB SDRAM
Store 2 MB of Flash
VME Bus VME 64 (Version 3. x)
Network interface 10/100 Ethernet (optional high-speed Ethernet interface)
Serial ports 4 x RS-232 or 2 x RS-232 and 1 x RS-422/485
I/O interfaces include digital I/O, analog I/O, serial port, USB, parallel port, etc
Expansion slot 1 x PMC slot, 1 x PCMCIA slot
Power requirement+5V DC (standard power input)
Size 6U (233 x 160 x 40 mm)
The operating system supports VxWorks, Linux, RTOS (real-time operating system)
The protection level meets the requirements of industrial environment, with anti vibration, dust-proof, and waterproof properties
