Bently 149992-01 繼電器模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Bently 149992-01 繼電器模塊 是由 Bently Nevada（本特利·內華達）公司生產的一款用于工業設備和控制系統中的 繼電器模塊。Bently Nevada 是 GE Digital 旗下的一家公司，專注于 設備健康監測 和 預測性維護 系統，提供高質量的振動監測、機器保護和資產管理產品。
主要特點：
高可靠性與穩定性：
- Bently 149992-01 繼電器模塊具有 高可靠性，設計用于工業環境中對 系統安全和保護 至關重要的應用。它可以在設備發生故障時，迅速切斷電路或發出報警信號，從而防止更大的系統損害。
多功能保護與控制：
- 該繼電器模塊可用于 設備保護 和 報警系統。它可以接入傳感器或監測系統，實時監測設備運行狀態，并在設備運行異常時觸發保護機制。
- 繼電器模塊支持 延時設置 和 多種報警功能，可以根據不同應用需求調節，確保設備在出現問題時及時采取適當?shù)拇胧?/li>
寬廣的應用場景：
- 該繼電器模塊主要應用于 振動監測系統 和 機器保護系統。它可以集成在 Bently Nevada 3500 系列監測系統 中，提供可靠的故障診斷和實時報警。
- 同時，它也適用于其他工業自動化系統，如電力、石油天然氣、化工等行業的設備保護和報警需求。
易于集成：
- Bently 149992-01 繼電器模塊設計兼容現有的 Bently Nevada 3500 系列控制系統 和其他自動化控制系統。通過標準的接線和通信協議，它可以輕松集成到現有的監控和控制架構中，減少了安裝和配置的復雜性。
多種輸入輸出接口：
- 繼電器模塊支持多種類型的輸入信號，如 數字輸入 和 模擬輸入，以及輸出控制信號，能夠滿足復雜控制需求。
- 提供 報警輸出 和 繼電器切換輸出，能夠直接控制外部設備，如警報器、停機控制等。
緊湊與堅固的設計：
- 繼電器模塊具備堅固的外殼設計，適應惡劣環境中的使用，能夠承受震動、溫度變化和電磁干擾等挑戰。
- 緊湊的外形 使得它能夠輕松安裝在標準的工業機架中，節省空間并方便維護。
應用領域：
振動監測與設備保護：
- 用于 Bently Nevada 3500 系列振動監測系統，可以監控機器的運行狀態（如電機、泵、風機等）并在設備出現異常時發出報警或斷電保護。
- 它可以檢測機器是否存在振動過大、溫度過高、負載過重等異常情況，并及時切斷電源，防止設備損壞。
工業控制系統：
- 適用于 工業自動化系統 中的各種保護和控制任務，如 壓力監測、流量監控 等關鍵參數的報警與保護功能。
- 在 油氣、化工、電力等重工業 中，為關鍵設備提供及時的故障報警與防護，確保設備的安全運行。
機器健康管理：
- 集成于 健康監測系統 中，用于實時監控設備的運行狀態，并及時觸發預警系統，幫助維護人員提前識別設備潛在故障。
能源與發電行業：
- 在 發電廠、變電站 等關鍵基礎設施中，提供電力設備的安全保護，及時報警和斷開故障設備，防止進一步的損壞。
技術規格：
| 參數 | 說明 |
|---|---|
| 輸入信號類型 | 數字輸入、模擬輸入（具體取決于應用） |
| 輸出信號類型 | 繼電器輸出（常開/常閉），報警輸出 |
| 額定工作電壓 | 24V DC（根據具體型號，可能有所不同） |
| 繼電器額定電流 | 5A (常開/常閉繼電器輸出) |
| 工作溫度范圍 | -40°C 至 +70°C（具體取決于應用環境） |
| 防護等級 | IP20 或根據具體要求，適合工業環境 |
| 尺寸 | 標準工業尺寸，適配 3500 系列機架 |
| 電氣接口 | 帶連接端子，支持標準工業接線方式 |
| 響應時間 | 毫秒級響應，確保及時的保護反應 |
| 工作濕度范圍 | 0% 至 95% RH，非凝結狀態 |
英文資料：
Bently 149992-01 Relay Module is a relay module produced by Bently Nevada Corporation for use in industrial equipment and control systems. Bently Nevada is a company under GE Digital that focuses on equipment health monitoring and predictive maintenance systems, providing high-quality vibration monitoring, machine protection, and asset management products.
Main features:
High reliability and stability:
The Bently 149992-01 relay module has high reliability and is designed for applications that are critical to system safety and protection in industrial environments. It can quickly cut off the circuit or issue an alarm signal in case of equipment failure, thereby preventing greater system damage.
Multi functional protection and control:
This relay module can be used for equipment protection and alarm systems. It can be connected to sensors or monitoring systems to monitor the real-time operation status of devices and trigger protection mechanisms in case of abnormal device operation.
The relay module supports delay setting and multiple alarm functions, which can be adjusted according to different application requirements to ensure that appropriate measures are taken in a timely manner when equipment problems occur.
Wide application scenarios:
This relay module is mainly used in vibration monitoring systems and machine protection systems. It can be integrated into the Bently Nevada 3500 series monitoring system, providing reliable fault diagnosis and real-time alarms.
At the same time, it is also applicable to equipment protection and alarm requirements in other industrial automation systems, such as power, oil and gas, chemical and other industries.
Easy to integrate:
The Bently 149992-01 relay module is designed to be compatible with existing Bently Nevada 3500 series control systems and other automation control systems. Through standard wiring and communication protocols, it can be easily integrated into existing monitoring and control architectures, reducing the complexity of installation and configuration.
Multiple input/output interfaces:
The relay module supports multiple types of input signals, such as digital and analog inputs, as well as output control signals, which can meet complex control requirements.
Provide alarm output and relay switching output, which can directly control external devices such as alarms, shutdown control, etc.
Compact and sturdy design:
The relay module has a sturdy housing design that is suitable for use in harsh environments and can withstand challenges such as vibration, temperature changes, and electromagnetic interference.
The compact appearance allows it to be easily installed in standard industrial racks, saving space and facilitating maintenance.
Application areas:
Vibration monitoring and equipment protection:
Used for Bently Nevada 3500 series vibration monitoring system, it can monitor the operating status of machines (such as motors, pumps, fans, etc.) and issue alarms or power-off protection in case of equipment abnormalities.
It can detect whether the machine has abnormal conditions such as excessive vibration, high temperature, and heavy load, and cut off the power supply in a timely manner to prevent equipment damage.
Industrial control system:
Suitable for various protection and control tasks in industrial automation systems, such as alarm and protection functions for key parameters such as pressure monitoring and flow monitoring.
In heavy industries such as oil and gas, chemical, and power, timely fault alarm and protection are provided for key equipment to ensure the safe operation of the equipment.
Machine Health Management:
Integrated into the health monitoring system, it is used to monitor the real-time operation status of equipment and trigger warning systems in a timely manner, helping maintenance personnel identify potential equipment failures in advance.
Energy and power generation industry:
In key infrastructure such as power plants and substations, provide safety protection for power equipment, timely alarm and disconnect faulty equipment, and prevent further damage.
Technical specifications:
Parameter Description
Input signal type: digital input, analog input (depending on the application)
Output signal type: Relay output (normally open/normally closed), alarm output
Rated working voltage 24V DC (may vary depending on the specific model)
Rated current of relay 5A (normally open/normally closed relay output)
Working temperature range -40 ° C to+70 ° C (depending on the application environment)
Protection level IP20 or suitable for industrial environments according to specific requirements
Size standard industrial size, compatible with 3500 series rack
Electrical interface with connecting terminals, supporting standard industrial wiring methods
Response time in milliseconds to ensure timely protection response
Working humidity range 0% to 95% RH, non condensing state
