AMAT Applied Materials 0100-35565射頻互鎖模塊 PDF資料
1.產 品 資 料 介 紹：
一、產品概述
AMAT Applied Materials 0100-35565 射頻互鎖模塊是一種用于半導體設備射頻系統的安全控制模塊。它主要用于監控和管理射頻功率系統的安全狀態，通過互鎖邏輯確保射頻電源在異常狀態下自動斷開或報警，從而保護設備及工藝安全。該模塊通常與射頻電源、匹配器及控制器協同工作，是射頻系統安全運行的重要組成部分。
二、技術參數（推測整理）
部件類型：射頻安全互鎖模塊（RF Interlock Module）
功能定位：射頻系統互鎖監控與安全保護
接口類型：數字輸入/輸出接口，用于連接射頻功率模塊、控制器及報警系統
邏輯功能：內置互鎖邏輯，監控射頻功率、電流和狀態信號
安裝方式：模塊化設計，可安裝于控制機箱或射頻電源附近
電源要求：典型工業電源（+5V、+12V 或背板供電）
保護功能：具備過流、短路、異常狀態檢測和信號隔離
環境適應性：工業級設計，適應半導體潔凈室及高電磁干擾環境
版本修訂：可能存在不同版本（Rev A/B 等），在接口數量或邏輯功能上有所差異
三、應用場景
射頻功率系統安全保護：在射頻異?；蚬收蠒r(shí)自動斷開電源
工藝保護：防止在非安全狀態下射頻功率激活，保護設備和工藝
閉環控制配合：與射頻匹配器及控制器協作，實現安全控制
報警與信號反饋：向主控系統提供射頻狀態和故障信息
四、產品優勢
高安全性：實時監控射頻功率及狀態，防止設備和工藝損壞
模塊化設計：便于安裝、維護和替換
智能互鎖邏輯：內置射頻安全邏輯，自動響應異常狀態
兼容性強：與 AMAT 射頻系統及控制模塊高度兼容
工業級可靠性：適應半導體潔凈室及高干擾環境
AMAT Applied Materials 0100-35565射頻互鎖模塊 英文介紹
1、 Product Overview
AMAT Applied Materials 0100-35565 RF Interlock Module is a safety control module used in semiconductor equipment RF systems. It is mainly used to monitor and manage the safety status of RF power systems, ensuring automatic disconnection or alarm of RF power supply in abnormal states through interlocking logic, thereby protecting equipment and process safety. This module usually works in conjunction with the RF power supply, matching device, and controller, and is an important component of the safe operation of the RF system.
2、 Technical parameters (speculated and organized)
Component type: RF Interlock Module
Functional positioning: RF system interlock monitoring and security protection
Interface type: Digital input/output interface, used to connect RF power modules, controllers, and alarm systems
Logic function: Built in interlock logic, monitoring RF power, current, and status signals
Installation method: Modular design, can be installed near the control chassis or RF power supply
Power requirements: Typical industrial power supply (+5V,+12V or backplane power supply)
Protection function: equipped with overcurrent, short circuit, abnormal state detection and signal isolation
Environmental adaptability: Industrial grade design, suitable for semiconductor cleanrooms and high electromagnetic interference environments
Version revision: There may be different versions (Rev A/B, etc.) with differences in the number of interfaces or logical functions
3、 Application scenarios
RF power system safety protection: automatically disconnect power supply in case of RF abnormality or failure
Process protection: prevent RF power activation in non safe states, protect equipment and processes
Closed loop control coordination: Collaborate with RF matching devices and controllers to achieve safe control
Alarm and signal feedback: Provide RF status and fault information to the main control system
4、 Product advantages
High security: Real time monitoring of RF power and status to prevent equipment and process damage
Modular design: easy to install, maintain, and replace
Intelligent interlock logic: Built in RF safety logic, automatically responds to abnormal states
Strong compatibility: highly compatible with AMAT RF system and control module
Industrial grade reliability: suitable for semiconductor cleanrooms and high interference environments
