溫度較低的冷卻水由換熱器下部進入換熱器，與循環空氣換熱后，由換熱器上部流出。被加熱后的冷卻水流至冷卻塔等冷卻設備進行冷卻，經冷卻降溫的冷卻水經水泵再次進入換熱器對循環空氣進行冷卻，如此循環。
圖5 水路循環
5.電控系統組成
系統由整流變壓器、功率單元柜、水冷控制系統、PLC控制柜、工控機、監控畫面組成。PLC柜主要采集變頻器的開關量信號、模擬量信號，開關柜的電能信號、水冷控制系統的流量、溫度等信號，通過監控畫面顯示并達到遠程控制目的。系統框圖如下：
圖6 電控系統框圖
變頻器主控PLC控制總的調速任務，包括變頻器的調速控制及與機組邏輯控制PLC系統（西門子416系統）的通訊。變頻裝置與機組邏輯控制PLC系統采用點對點的通訊方式。變頻器主控PLC可接收機組邏輯控制PLC系統的中控指令、中控投入、中控解除、變頻投入、變頻不投入、停止加速、機組預放電等；變頻器主控PLC發給機組邏輯控制PLC系統的信號有：機組加速中，機組加速到位、動態回令（機組預防電條件滿足）、變頻器事故綜合、滑差提電極到預定位、靜態回令、機組加速，接受滑差PLC的電極位置（預定位、低位、高位）、速度到達等信號。
6.上位控制系統
項目中上位機監控系統，選用工控機與PLC進行網絡通訊；利用WINCC組態監控軟件，實現實時多畫面監控，以達到監控設備運行狀態的目的。監控畫面主要包括：主界面、報警歸檔頁面、數據歸檔頁面、3個機組頁面、以及各個變頻器的數據曲線頁面等。
圖7 西南核工業上位監控系統
1.變頻器與PLC控制系統通訊：變頻器與PLC控制系統之間物理通訊為485通訊，通訊協議為Modbus/RTU協議，可選Profibus協議。
2.自動控制系統：設備監控核心采用西門子S7系列可編程控制器，結合現場傳感器和設備控制接口實現電機及附屬設備的邏輯控制和運行狀態、參數的實時在線監測，并采用PLC冗余系統，自動切換。PLC系統實時采集高壓變頻器的運行狀態，并實時控制變頻器運行。
3.在線監控系統：采用大屏幕真彩液晶顯示器；按照雙機冗余互為備用模式設計，置專業工業控制組態軟件實時顯示運行工況參數，動態顯示工藝流程圖形和設備運行狀態。 and the memory of s7-1200 is also slightly insufficient.
In addition, there are not many HMI supporting S7 1200, and there are few options.
(reflow) refers to the paste soft paste pre distributed to the printed board pad by remelting
To realize the soft soldering of mechanical and electrical connection between the welding end or pin of surface assembled components and the bonding pad of printed board. It provides a heating environment to heat and melt the solder paste, so as to make the surface mount components and
B pad through solder paste
According to the technical characteristics of reflow welding, the equipment reliably combined together can be divided into gas-phase reflow, infrared reflow and hot air reflow. At present, the mainstream equipment adopts hot air reflow. Hot air reflow is to make the colloidal flux (solder paste) physically react under a certain high-temperature air flow to achieve SMD welding. Because this hot air flow circulates inside the welding machine to achieve the purpose of welding, so, In the industry, the equipment that uses the original principle of thermal reflow to realize the
