MVME709-1工控備件模塊
（或其中的子分支）。控制驅動器驅動器窗口2 5-5如果可以成功進行控制，驅動器的狀態圖像和名稱、用于輸入?yún)⒖贾档淖侄我约懊畎粹o將顯示在驅動器面板工具欄中。即使驅動器狀態刷新已關閉，瀏覽樹窗格中驅動器的狀態圖像也將刷新。此外，驅動器菜單中的控制命令已啟用，“獲取控制”命令已切換到“釋放控制”。如果受控制的驅動器沒有可用的命令，則驅動器面板工具欄中的相應按鈕將隱藏，并且在驅動器菜單中禁用（灰色）。交流和直流驅動器重復使用一些位置來顯示不同命令的按鈕，而其他類型的驅動器中不存在這些按鈕。驅動器菜單中顯示的命令將相應更改。默認情況下，顯示控制項目集中的項目并使其聯機?？刂乞?qū)動器5-6驅動器窗口2 2.1.1失去控制如果驅動器中的看門狗因某種原因關閉，或出現通信故障，您的電腦會發出蜂鳴聲，控制將自動釋放。在這種情況下，故障記錄器通常會記錄面板丟失故障。2.1.2禁用操作為了最大限度地降低失去控制的可能性，在采取控制時，將禁用一些可能導致沉重通信負載的操作。例如，禁用以下操作：?保存、比較、導出、打印和下載驅動器參數。?上載、恢復和下載系統軟件。另請參閱：控制驅動器獲取和釋放控制命令驅動器釋放控制2.2釋放控制當您不再需要控制驅動器時，應釋放控制。在釋放控制之前，如果可能，我們建議將參考值設置為零并停止驅動。要釋放對驅動器的控制，請首先通過在瀏覽樹窗格中單擊該驅動器來選擇該驅動器。但是，不必選擇其根。選擇其任何分支機構即可。然后，單擊驅動器面板工具欄中的獲取/釋放控制按鈕，選擇驅動器菜單中的釋放控制命令，或按Alt+F2?？刂乞?qū)動器驅動器窗口2 5-7也可以在上下文菜單中找到釋放控制命令。您可以通過右鍵單擊瀏覽樹窗格中的驅動器（或其中的子分支）來獲得該命令。如果可以成功釋放控制，則會清除驅動面板工具欄。此外，“驅動”菜單中的控制命令被禁用（灰色），“釋放控制”命令已切換為“獲取控制”。
(or a sub-branch within it) in the browse tree pane. Controlling Drives DriveWindow 2 5-5 If control could be taken successfully, status image and name of the drive, field for entering the reference value, and command buttons are shown in the drive panel toolbar. The status image of the drive in the browse tree pane will be refreshed even if drive status refreshing is off. Also, control commands in the Drive menu are enabled, and the Take Control command has toggled to Release Control. If the drive under control does not have a command available, the corresponding button in the drive panel toolbar is hidden, and in the Drive menu it is disabled (grayed). AC and DC drives reuse some positions to show buttons for different commands, which do not exist in the other type of drive. The commands shown in the Drive menu are changed correspondingly. By default, the items in the control item set are shown and put on-line. Controlling Drives 5-6 DriveWindow 2 2.1.1 Losing control If the watchdog in the drive goes off for some reason, or there is a communication failure, your PC beeps and control is automatically released. The fault logger usually logs a PANEL LOSS fault in such a case. 2.1.2 Disabled operations To minimize the probability of losing control, some operations, which may cause heavy communication load, are disabled, while control is taken. For example, the following operations are disabled: ? Saving, comparing, exporting, printing, and downloading of drive parameters. ? Uploading, restoring, and downloading system software. See Also: Controlling Drives Taking and Releasing Control Commanding a Drive Release Control 2.2 Release Control When you do not need to control a drive any more, you should release the control. Before releasing control, we recommend, if possible, to set the reference value to zero and stop the drive. To release control of a drive, select first the drive by clicking it in the browse tree pane. It is not necessary to select its root, however. Selection of any of its sub-branches will do. Then either, click the take/release control button in the drive panel toolbar, select the Release Control command in the Drive menu, or press Alt+F2. Controlling Drives DriveWindow 2 5-7 The Release Control command can also be found in the context menu, which you get by clicking with the right mouse button the drive (or a sub-branch within it) in the browse tree pane. If control could be released successfully, the drive panel toolbar is cleared. Also, control commands in the Drive menu are disabled (grayed), and the Release Control command has toggled to Take Control.
