MVME2603-1161控制器模塊
危險氣體和粉塵環境的1區、2區、21區和22區覆蓋范圍涵蓋了大多數工業垂直領域的大多數應用。危險位置解決方案可作為現場安裝的單個組件購買。十種不同的操作員類型與底座安裝或面板安裝接觸塊和電源模塊配對。新的面板安裝設計允許快速、方便地現場安裝面板安裝蓋附件，在需要時提供IP66/IP67環境等級。我們的“-EX”產品還提供其他組裝站配置。配置控制站時，可以選擇雙按鈕和按鍵操作的選擇器開關。我們的緊急停止推拉裝置上可以增加一個鎖緊裝置，并且可以為按鈕和選擇器開關操作員選擇一個鎖蓋。最多可將三個800G機柜“組合”在一起，提供一個具有多達九種不同操作員功能的命令和指示站。特點和優點?擴展了全球危險場所使用的認證–ATEX（歐洲）–IECEx（非洲、澳大利亞、印度等）–INMETRO（巴西）–NEPSI（中國）?適用于危險氣體和粉塵環境–1區、2區、21區、22區–防火、增安、，和外殼保護類型?面板安裝設計–面板安裝蓋安裝的兩個選項卡–800G-APMC面板安裝蓋附件可現場安裝在面板背面，以達到額外的IP66和IP67等級–組件保持認證覆蓋范圍?裝配式站配置便于選擇和安裝，包括：–雙按鈕–按鍵操作選擇開關–鎖緊保護裝置、鎖緊蓋–附加卡扣式顏色蓋變體?可作為單個組件或標準或定制組裝工位提供，以實現最佳靈活性全球危險場所解決方案的來源出版物800G-PP001A-EN-P–2019年5月版權所有?2019 Rockwell Automation，Inc.。保留所有權利。在美國印刷。
和Rockwell Software是羅克韋爾自動化公司的商標。不屬于羅克韋爾自動公司的商標是其各自公司的財產。公告800G系列比較公告800G解決方案公告800G“-EX”解決方案認證cULus、ATEX（過時）ATEX（更新）、IECEx、INMETRO、NEPSI危險區域分類I級2區、I級1區1區、21區環境等級IP66、IP67（選擇配置）、4X型IP64、IP66、，IP67（選擇配置）與800G-APMC（面板安裝蓋附件）的兼容性否是否允許現場安裝站/空外殼可供銷售是否組裝站標準、成組、定制標準、成組，自定義目錄編號字符串現有（不會更改）“-EX”后綴（表示ATEX和IECEx）ATEX&IECEx組裝站擴展說明操作員代碼雙瞬時按鈕U 2位置鍵選擇開關R 3位置鍵選擇按鈕S緊急停止推拉帶鎖緊防護裝置4非照明按鈕帶鎖緊蓋5照明按鈕帶鎖定蓋6 2位置帶鎖蓋的選擇器開關8 3位置選擇器開關帶鎖蓋9完整組裝的站點目錄號目錄號描述800G-144N3-EX紅色急停按鈕，帶2個NC觸點和鎖緊防護裝置，M20塑料電纜壓蓋800G-144A3-EX紅色緊急停按鈕，帶有1個NO 1 NC觸點和鎖定防護裝置，M20塑料電纜壓蓋800G-1R1A3-EX 2位置保持鍵選擇開關，帶1 NO 1 NC觸點，左鍵拆除，M20塑料電纜密封套800G-1UXA8-EX雙按鈕，帶1 NO1 NC觸點；M20金屬電纜壓蓋800G-2FAA5A3-EX啟動按鈕，帶一NO 1 NC接觸，M20塑料電纜壓蓋800G-2F3A54A3-EX綠色按鈕，帶1 NO 1 NC觸點，紅色按鈕，帶一NO 1NC觸點和鎖定蓋，M20塑料電纜填料壓蓋800G-2P4DUXA3-EX紅色指示燈，雙按鈕，帶有1 NO 1NC接觸，M20塑料電纜壓蓋800G-3F3AF4A44A3-EX綠色按鈕
The coverage of Zones 1, 2, 21, and 22 for hazardous gas and dust environments covers most applications in most industrial verticals. Hazardous location solutions can be purchased as a single component for field installation. Ten different operator types are paired with base mounted or panel mounted contact blocks and power modules. The new panel mounting design allows quick and easy field installation of panel mounting cover accessories, providing IP66/IP67 environmental ratings when required. Our "- EX" products also offer other assembly station configurations. When configuring the control station, it is possible to select a selector switch operated by two buttons and keys. A locking device can be added to our emergency stop push-pull device, and a lock cover can be selected for the button and selector switch operator. Up to three 800G cabinets can be "combined" together to provide a command and indication station with up to nine different operator functions. Features and advantages ? Expanded the global certification for use in hazardous locations – ATEX (Europe) – IECEx (Africa, Australia, India, etc.) – INMETRO (Brazil) – NEPSI (China) ? Suitable for hazardous gas and dust environments – Zone 1, 2, 21, 22 – Fire protection (db), increased safety (eb), And enclosure (tb) protection type ? Panel mounting design – two tabs for panel mounting cover installation – 800G-APMC panel mounting cover accessories can be installed on the back of the panel in the field to achieve additional IP66 and IP67 levels – components maintain certified coverage ? Assembled station configuration is easy to select and install, including: – dual button – key operated selector switch – locking protection device Locking cover – additional snap on color cover variants ? Available as a single component or as a standard or custom assembly station for optimal flexibility Source publication 800G-PP001A-EN-P – May 2019 ? 2019 Rockwell Automation，Inc.。 All rights reserved. Printed in the United States.
And Rockwell Software are trademarks of Rockwell Automation. Trademarks not belonging to Rockwell Automation are the property of their respective companies. Announcement 800G Series Comparison Announcement 800G Solution Announcement 800G "- EX" Solution Certification cULus, ATEX (outdated) ATEX (updated), IECEx, INMETRO, NEPSI Hazardous Area Classification Class I Zone 2, Class I Zone 1 Zone 1, Zone 21 Environmental Class IP66, IP67 (optional configuration), 4X type IP64, IP66, Whether the compatibility between IP67 (optional configuration) and 800G-APMC (panel mounting cover accessories) allows the on-site installation station/empty shell to be sold, whether the assembly station standard, grouping, customized standard, grouping, Custom catalog number string existing (will not change) "- EX" suffix (for ATEX and IECEx) ATEX&IECEx Assembly Station Extension Description Operator Code Double Instantaneous Button U 2 Position Key Selector Switch R 3 Position Key Selector Button S Emergency Stop Push Pull Button with Locking Guard 4 Non Illuminated Button with Locking Cover 5 Illuminated Button with Locking Cover 6 2 Position Selector Switch with Locking Cover 8 3 Position Selector Switch with Locking Cover 9 Completely Assembled Station Catalog Number Catalog Number Description 800G-144N3-EX Red Emergency Stop Button with 2 NC Contacts and Locking Guard, M20 plastic cable gland 800G-144A3-EX red emergency stop button, with 1 NO 1 NC contact and locking protection device, M20 plastic cable gland 800G-1R1A3-EX 2 position holding key selector switch, with 1 NO 1 NC contact, left key removal, M20 plastic cable gland 800G-1UXA8-EX double button, with 1 NO 1 NC contact; M20 metal cable gland 800G-2FAA5A3-EX start button, with one NO 1 NC contact, M20 plastic cable gland 800G-2F3A54A3-EX green button, with one NO 1 NC contact, red button, with one NO 1NC contact and locking cover, M20 plastic cable gland 800G-2P4DUXA3-EX red indicator light, double buttons, with one NO 1NC contact, M20 plastic cable gland 800G-3F3AF4A44A3-EX green button
