GE 605-109114-004數字輸入模塊
1.產 品 資 料 介 紹：
中文資料：
以下過程概述了GE 605-109114-004在VMEbus機箱中的安裝以及網絡環形拓撲的設置。GE 605-109114-004可以安裝在任何插槽中，但插槽1除外，插槽1通常是為系統控制器保留的。1.在機箱中安裝板之前，確保所有開關都設置為所需的操作模式。請參閱第36頁的開關/跳線配置和位置。2.在電源關閉的情況下，將GE 605-109114-004安裝到機箱中，確保板連接器與背板連接器牢固配合。
3.使用位于前面板頂部和底部的兩個螺釘將GE 605-109114-004固定到機箱。4.將光纖電纜連接到TX和RX連接器。5.將連接到TX的光纖電纜布線到環中下一個板的RX連接器。將光纖電纜從該板的TX連接到下一個板的RX連接器。重復此步驟，直到環中的最后一個節點將其TX路由到第一個節點的RX。有關六節點環的示例，請參閱第47頁的圖2-9。
英文資料：
The following procedure outlines the installation of the GE 605-109114-004 in a VMEbus chassis and the set-up of the network ring topology. The GE 605-109114-004 can be installed in any slot with the exception of slot one, which normally is reserved for the system controller. 1. Before installation of the board in the chassis, ensure that all switches are set for the desired mode of operation. Refer to Switch/Jumper Configuration and Location on page 36. 2. With the power turned OFF, install the GE 605-109114-004 into the chassis, making sure that the board connectors are firmly mated to the backplane connectors.
3. Secure the GE 605-109114-004 to the chassis using the two screws located at the top and bottom of the front panel. 4. Connect the fiber-optic cables to the TX and RX connectors. 5. Route the fiber-optic cable connected to TX to the RX connector of the next board in the ring. Connect the fiber-optic cable from that board’s TX to the RX connector of the next board. Repeat this step until the last node in the ring routes its TX to the RX of the first node. Refer to Figure 2-9 on page 47 for an example of a six node ring.
2.產 品 展 示
