MOOG D634-501A比例閥 PDF資料
1.產 品 資 料 介 紹：
MOOG D634-501A 比例閥說明
一、總體概述
MOOG D634-501A 是 D634 系列高性能液壓比例閥，廣泛應用于工業自動化、機床控制、測試平臺及航空液壓系統。
該比例閥能夠?qū)㈦娦盘柧_轉換為液壓流量或壓力輸出，實現執行器位置、速度或力的精密控制，適用于需要高精度和高動態響應的液壓系統。
二、主要特性
控制類型：比例閥，用于液壓執行器的精確流量或壓力控制
控制方式：電液控制，通過直流電信號調節液壓流量
閥口類型：四口三位或三口二位結構，支持雙向液壓控制
響應速度：高動態響應，適合快速控制系統
線性特性：輸出流量與輸入信號高度線性，確?？刂凭?/p>
重復性：高重復精度，保證執行器動作穩定
電氣接口：標準 ±10V 或 ±12V 信號輸入，根據系統配置而定
三、功能特點
高精度控制
D634-501A 能夠?qū)崿F(xiàn)精確的液壓流量和壓力調節，滿足高要求的液壓控制任務。快速響應
閥體結構優化，在高動態系統中快速響應，減少滯后和過沖。耐用可靠
閥體和內部組件采用高精度加工及耐磨材料，適應長期工業環境使用。廣泛適用性
可用于機械臂、飛行控制、工業自動化及測試平臺等液壓系統。調試方便
支持通過電氣信號調節閥工作特性，便于系統集成和性能優化。
MOOG D634-501A比例閥 英文介紹
MOOG D634-501A Proportional Valve Description
1、 Overall Overview
MOOG D634-501A is a high-performance hydraulic proportional valve of the D634 series, widely used in industrial automation, machine tool control, testing platforms, and aviation hydraulic systems.
This proportional valve can accurately convert electrical signals into hydraulic flow or pressure output, achieving precise control of actuator position, speed, or force, and is suitable for hydraulic systems that require high precision and high dynamic response.
2、 Main characteristics
Control type: Proportional valve, used for precise flow or pressure control of hydraulic actuators
Control method: electro-hydraulic control, regulating hydraulic flow through DC electrical signals
Valve port type: four port three position or three port two position structure, supporting bidirectional hydraulic control
Response speed: High dynamic response, suitable for fast control systems
Linear characteristics: The output flow rate is highly linear with the input signal, ensuring control accuracy
Repeatability: High repeatability accuracy ensures stable actuator action
Electrical interface: Standard ± 10V or ± 12V signal input, depending on system configuration
3、 Functional Features
high-precision control
D634-501A can achieve precise hydraulic flow and pressure regulation, meeting high demand hydraulic control tasks.
quick response
Optimization of valve body structure for rapid response in high dynamic systems, reducing hysteresis and overshoot.
durable and reliable
The valve body and internal components are made of high-precision machining and wear-resistant materials, suitable for long-term industrial environment use.
wide applicability
Can be used for hydraulic systems such as robotic arms, flight control, industrial automation, and testing platforms.
Easy debugging
Support regulating valve operating characteristics through electrical signals, facilitating system integration and performance optimization.
MOOG D634-501A比例閥 產品展示
