ABB 5SHY3545L0014 3BHE023784 3BHE019719R0101 GVC736BE101 可控硅模塊 PDF資料
1.產 品 資 料 介 紹：
產品定位
該模塊屬于 ABB 的功率電力電子模塊類別（可控硅/IGCT/可控模塊）——也可用于高功率整流/逆變、驅動大電流設備的應用。
型號 “5SHY3545L0014” 與 “GVC736BE101” 提及可控硅模塊、THYRISTOR 模塊或功率半導體模塊，相對于低壓控制模塊更偏“功率部件”而非邏輯控制卡。
用途通常包括大型電機驅動、變頻器、高壓整流、重載工業設備、變電系統等場景。
主要特點
高功率承載：
模塊設計支持大電流、大電壓環境，對負載能力要求極高。適用于工業整流、逆變、驅動大功率設備。可控硅／功率半導體技術：
使用可控硅（thyristor）、IGCT（集成門極換流晶閘管）或類似功率器件技術，以實現大功率控制。工業級設計：
具備優良的熱管理、散熱結構和高電壓絕緣設計，適合嚴苛工業環境（如高溫、高振動、大電流場合）。兼容系統集成：
模塊通常與 ABB 的驅動、變頻器、DCS、整流系統等配合使用，可插入或安裝于特定機柜或系統中。可靠性與保護機制：
包含過流、沖擊電流、短路、溫度異常等保護設計，保障模塊在運行中安全穩定。模塊化封裝：
便于替換維修、系統升級或擴容。用戶可根據系統需求更換模塊或整合至更大功率系統。典型應用廣泛：
大型電機驅動系統（如冶金、采礦、石化）
高壓整流／逆變系統
可再生能源系統、高功率變換器
電力系統的功率控制與轉換單元
ABB 5SHY3545L0014 3BHE023784 3BHE019719R0101 GVC736BE101 可控硅模塊 英文介紹
Product positioning
This module belongs to ABB's power electronics module category (thyristor/IGBT/controllable module) - it can also be used for high-power rectification/inversion and driving high current equipment applications.
The models "5SHY3545L0014" and "GVC736BE101" mention thyristor modules, THYRISTOR modules, or power semiconductor modules, which are more focused on "power components" rather than logic control cards compared to low-voltage control modules.
The applications usually include large motor drives, frequency converters, high-voltage rectifiers, heavy-duty industrial equipment, substation systems, and other scenarios.
Main Features
High power carrying capacity:
The module design supports high current and high voltage environments, with extremely high requirements for load capacity. Suitable for industrial rectification, inversion, and driving high-power equipment.
Controllable silicon/power semiconductor technology:
Use thyristor, IGCT (integrated gate commutated thyristor) or similar power device technologies to achieve high-power control.
Industrial grade design:
Featuring excellent thermal management, heat dissipation structure, and high-voltage insulation design, it is suitable for harsh industrial environments such as high temperature, high vibration, and high current situations.
Compatible system integration:
Modules are usually associated with ABB's drivers, frequency converters DCS、 The rectifier system can be used in conjunction with other components and can be inserted or installed in specific cabinets or systems.
Reliability and protection mechanism:
Including protection designs for overcurrent, surge current, short circuit, temperature anomalies, etc., to ensure the safe and stable operation of the module.
Modular packaging:
Easy to replace, repair, upgrade or expand the system. Users can replace modules or integrate them into higher power systems according to system requirements.
Typical applications are widely used:
Large motor drive systems (such as metallurgy, mining, petrochemicals)
High voltage rectification/inverter system
Renewable energy systems, high-power converters
Power Control and Conversion Unit of Power System
ABB 5SHY3545L0014 3BHE023784 3BHE019719R0101 GVC736BE101 可控硅模塊 產品展示
