TRICONEX 3625數字 I/O 模塊 PDF資料
1.產 品 資 料 介 紹：
TRICONEX 3625 數字 I/O 模塊 產品特點：
產品概述：
TRICONEX 3625 是 Tricon 安全控制系統中的數字輸入/輸出模塊，用于采集現場數字信號并執行開關控制指令，是工業安全儀表系統（SIS）中的關鍵組件。三重冗余架構 (TMR)：
模塊采用 Triple Modular Redundant（三模冗余） 設計，三個通道同時運行，通過投票機制確保系統對單點故障具有容錯能力。數字輸入/輸出通道：
提供多路獨立數字輸入/輸出
輸入支持干接點或有源信號
輸出可驅動繼電器或晶體管設備
每個通道獨立隔離，防止干擾
高可靠性與安全等級：
模塊符合 IEC 61508 SIL3 安全完整性標準，適合關鍵安全控制和緊急停機系統。自診斷功能：
實時監測通道狀態、信號完整性和模塊健康狀況，異常時可自動隔離故障通道并發出報警。系統通信：
通過 Tricon 總線與主處理器模塊 (如 3008) 高速通信，實現邏輯控制和數據同步。熱插拔支持：
模塊可在帶電情況下更換或維護，減少系統停機時間。工業環境適應性：
設計滿足工業級要求，具備抗震、防塵、防電磁干擾能力，適用于惡劣工況。典型應用：
石油化工及天然氣裝置的緊急停機系統 (ESD)
電廠關鍵設備安全控制
海上平臺、LNG 終端及煉化廠安全儀表系統
化工過程聯鎖及設備保護系統
TRICONEX 3625數字 I/O 模塊 英文介紹
TRICONEX 3625 Digital I/O Module Product Features:
Product Overview:
TRICONEX 3625 is a digital input/output module in the Tricon safety control system, used to collect on-site digital signals and execute switch control instructions. It is a key component in industrial safety instrumented systems (SIS).
Triple Redundancy Architecture (TMR):
The module is designed with Triple Modular Redundant (the third mock examination Redundant), and three channels run simultaneously. The voting mechanism ensures that the system has fault tolerance for single point of failure.
Digital input/output channels:
Provide multiple independent digital inputs/outputs
Input supports dry contacts or active signals
Output can drive relay or transistor devices
Each channel is independently isolated to prevent interference
High reliability and safety level:
The module complies with the IEC 61508 SIL3 safety integrity standard and is suitable for critical safety control and emergency shutdown systems.
Self diagnostic function:
Real time monitoring of channel status, signal integrity, and module health status, automatically isolating faulty channels and issuing alarms in case of abnormalities.
System communication:
Through high-speed communication with the main processor module (such as 3008) via the Tricon bus, logic control and data synchronization are achieved.
Hot swappable support:
Modules can be replaced or maintained when powered on, reducing system downtime.
Industrial environment adaptability:
Designed to meet industrial grade requirements, with seismic, dust, and electromagnetic interference resistance, suitable for harsh working conditions.
Typical applications:
Emergency Shutdown System (ESD) for Petrochemical and Natural Gas Plants
Safety control of key equipment in power plants
Safety Instrumented Systems for Offshore Platforms, LNG Terminals, and Refineries
Chemical process interlocking and equipment protection system
TRICONEX 3625數字 I/O 模塊 產品展示
