TRICONEX 3805E模擬輸出模塊 PDF資料
1.產 品 資 料 介 紹：
TRICONEX 3805E 模擬輸出模塊 產品特點
產品概述：
TRICONEX 3805E 是 Tricon 安全控制系統（Tricon Safety System）中的關鍵模擬輸出模塊，用于將數字控制信號轉換為工業現場可用的模擬信號，實現對執行器、閥門、調節器等設備的精確控制。輸出類型：
支持多路獨立模擬輸出通道（電流/電壓型），常用于 4–20?mA 或 0–10?V 信號輸出。
可直接驅動閥門定位器、伺服控制器和其他工業執行設備。
三模冗余 (TMR) 架構：
模塊設計符合 Triconex TMR 標準，三個獨立通道同時運行，通過投票機制實現容錯。
提高系統可靠性和安全性，即使單通道出現故障，系統仍能正常運行。
高精度與穩定性：
輸出信號精度高，響應迅速，滿足工業過程控制對精度和動態響應的嚴格要求。
支持線性化和信號校準功能，確保輸出信號與實際控制需求一致。
診斷與自檢功能：
內置自檢和故障檢測機制，實時監控模塊狀態和輸出通道健康情況。
異常情況下自動隔離故障通道，向主處理器報警，提高系統可靠性。
系統集成：
可插入 Triconex 系統機架，與 3008 主處理器、3625/3664 I/O 模塊及 HMI 操作面板無縫協作。
支持與上位機、控制系統或安全儀表系統 (SIS) 集成，實現閉環控制。
工業級環境適應性：
具備抗電磁干擾、防震、防塵、防潮濕等特性，可在高溫、高濕或嚴苛工業環境下穩定運行。
安全與應用：
符合 IEC 61508 SIL3 安全標準，適用于關鍵安全控制系統。
廣泛應用于石油化工、煉油廠、天然氣平臺、電廠及海上平臺的過程控制、閥門調節及緊急停機系統。
TRICONEX 3805E模擬輸出模塊 英文介紹
TRICONEX 3805E Analog Output Module Product Features
Product Overview:
TRICONEX 3805E is a key analog output module in the Tricon Safety System, used to convert digital control signals into analog signals that can be used on industrial sites, achieving precise control of actuators, valves, regulators, and other equipment.
Output type:
Supports multiple independent analog output channels (current/voltage type), commonly used for 4-20 mA or 0-10 V signal output.
It can directly drive valve positioners, servo controllers, and other industrial execution equipment.
The third mock examination Redundancy (TMR) architecture:
The module design complies with the Triconex TMR standard, with three independent channels running simultaneously and fault tolerance achieved through a voting mechanism.
Improve system reliability and security, even if a single channel fails, the system can still operate normally.
High precision and stability:
The output signal has high accuracy and fast response, meeting the strict requirements of industrial process control for accuracy and dynamic response.
Support linearization and signal calibration functions to ensure that the output signal is consistent with the actual control requirements.
Diagnostic and self checking functions:
Built in self checking and fault detection mechanism, real-time monitoring of module status and output channel health.
Automatically isolate the faulty channel in abnormal situations, alert the main processor, and improve system reliability.
System integration:
It can be inserted into the Triconex system rack and seamlessly works with the 3008 main processor, 3625/3664 I/O modules, and HMI operation panel.
Support integration with upper computer, control system or Safety Instrumented System (SIS) to achieve closed-loop control.
Industrial grade environmental adaptability:
It has the characteristics of anti electromagnetic interference, shock resistance, dust prevention, moisture resistance, etc., and can operate stably in high temperature, high humidity or harsh industrial environments.
Security and Application:
Compliant with IEC 61508 SIL3 safety standard, suitable for critical safety control systems.
Widely used in process control, valve regulation, and emergency shutdown systems for petrochemicals, refineries, natural gas platforms, power plants, and offshore platforms.
TRICONEX 3805E模擬輸出模塊 產品展示
