AEG MODICON AS-B550-000輸入輸出模塊 PDF資料
1.產 品 資 料 介 紹：
AEG Modicon AS-B550-000 輸入輸出模塊簡介
AEG Modicon AS-B550-000 是 Modicon 800 系列中的一款 綜合型輸入/輸出模塊（I/O Module），可同時處理開關量輸入與輸出信號。它適用于需要在有限機架空間內實現多功能信號處理的工業自動化系統，常用于設備聯鎖、機組控制與工藝監測。
主要功能特點
1. 輸入與輸出一體化設計
單模塊同時具備離散輸入與離散輸出功能
適用于采集按鈕、觸點、行程開關等信號
輸出可驅動繼電器線圈、小負載設備或邏輯觸發裝置
2. 工業級穩定運行
輸入電路具備抗干擾能力，輸出端提供可靠驅動
支持長時間 24 小時連續運行
適合電氣噪聲較強的工業現場
3. 良好的系統兼容性
直接安裝在 Modicon 800 系列標準機架
與 CPU、通訊模塊及其它 I/O 模塊協同工作
背板傳輸穩定，數據刷新快速
4. 使用與維護方便
模塊化卡件結構，插拔簡便
I/O 通道通常具備狀態指示，方便調試
適用于擴容、改造與替換舊模塊
典型應用領域
自動化生產線的輸入監測與輸出控制
設備啟停邏輯、互鎖和保護控制
工廠工藝系統的開關量采集與動作輸出
空間有限、需集成雙功能的控制柜
AEG MODICON AS-B550-000輸入輸出模塊 英文介紹
Introduction to AEG Modicon AS-B550-000 Input/Output Module
AEG Modicon AS-B550-000 is a comprehensive input/output module (I/O Module) in the Modicon 800 series, which can simultaneously process switch input and output signals. It is suitable for industrial automation systems that require multifunctional signal processing within limited rack space, commonly used for equipment interlocking, unit control, and process monitoring.
Main functional features
1. Integrated design of input and output
Single module with both discrete input and discrete output functions
Suitable for collecting signals such as buttons, contacts, travel switches, etc
Output can drive relay coils, small load devices, or logic triggering devices
2. Industrial grade stable operation
The input circuit has anti-interference capability, and the output terminal provides reliable driving
Support 24-hour continuous operation for a long time
Suitable for industrial sites with strong electrical noise
3. Good system compatibility
Directly installed on Modicon 800 series standard rack
Collaborate with CPU, communication module, and other I/O modules
Backplane transmission is stable, data refresh is fast
4. Easy to use and maintain
Modular card structure, easy to plug and unplug
I/O channels usually have status indicators for easy debugging
Suitable for expanding, renovating, and replacing old modules
Typical application areas
Input monitoring and output control of automated production lines
Equipment start stop logic, interlocking, and protection control
On/off value acquisition and action output of factory process system
Control cabinet with limited space and the need to integrate dual functions
AEG MODICON AS-B550-000輸入輸出模塊 產品展示
