SGDB-20VDY85 伺服控制器 PDF資料
1.產 品 資 料 介 紹：
YASKAWA SGDB-20VDY85 伺服控制器簡介
SGDB-20VDY85 是安川（YASKAWA）SGDB 系列中的一款交流伺服驅動器，主要用于控制安川早期系列的 AC 伺服電機。該系列以穩定性高、響應快和結構成熟著稱，在機械自動化設備中應用廣泛。
產品特點
可靠的速度與位置控制性能：驅動回路響應快速，可滿足中高速機械運動要求。
穩定性高：SGDB 系列以耐用和故障率低著稱，適合長期運行的設備。
兼容性好：常與安川對應容量的伺服電機配套使用，系統匹配度高。
過載保護全面：具備過流、過壓、編碼器異常、過溫等多種保護功能。
安裝維護方便：結構清晰、參數設置簡單，便于現場技術人員調試。
型號含義及容量
“20V” 代表驅動容量等級，多用于 2.0kW 等級 電機。
“DY85” 通常對應特定應用或特殊版本的設定參數與安裝形式。
典型技術范圍（SGDB 系列共性參考）
（不同版本略有差異，這里給你常規參數范圍）
適配電機功率：約 2.0kW
控制方式：速度/轉矩控制為主，部分機型支持簡易位置模式
電源類型：AC 輸入
控制接口：模擬量指令 + 基本 I/O 控制
保護功能：過載、欠壓/過壓、短路、編碼器異常等
常見應用場景
包裝機械
自動化搬運裝置
印刷與繞線設備
電子制造設備
工廠自動化改造項目（老設備替換需求特別多）
SGDB-20VDY85 伺服控制器 英文介紹
Introduction to YASKAWA SGDB-20VDY85 servo controller
SGDB-20VDY85 is an AC servo drive in the Yaskawa (YASKAWA) SGDB series, mainly used to control AC servo motors in the early Yaskawa series. This series is known for its high stability, fast response, and mature structure, and is widely used in mechanical automation equipment.
Product Features
Reliable speed and position control performance: The drive circuit responds quickly and can meet the requirements of medium and high-speed mechanical motion.
High stability: The SGDB series is known for its durability and low failure rate, making it suitable for long-term operation of equipment.
Good compatibility: often used in conjunction with servo motors of corresponding capacity in Yaskawa, with high system compatibility.
Comprehensive overload protection: equipped with multiple protection functions such as overcurrent, overvoltage, encoder abnormality, and overheating.
Easy installation and maintenance: The structure is clear, the parameter settings are simple, and it is convenient for on-site technicians to debug.
Model meaning and capacity
20V "represents the driving capacity level and is commonly used for 2.0kW level motors.
DY85 "usually corresponds to specific application or special version settings parameters and installation forms.
Typical Technical Scope (SGDB Series Common Reference)
(There are slight differences between different versions, here are the general parameter ranges for you)
Suitable motor power: about 2.0kW
Control mode: speed/torque control as the main mode, some models support simple position mode
Power type: AC input
Control interface: analog command+basic I/O control
Protection functions: overload, undervoltage/overvoltage, short circuit, encoder abnormality, etc
Common application scenarios
packaging machinery
Automated handling device
Printing and winding equipment
Electronic manufacturing equipment
Factory automation renovation project (with a high demand for replacing old equipment)
SGDB-20VDY85 伺服控制器 產品展示
